PSoC
®
3: CY8C36 Family Datasheet
Programmable System-on-Chip (PSoC
®
)
Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 001-53413 Rev. *P Revised September 3, 2012
General Description
With its unique array of configurable blocks, PSoC
®
3 is a true system level solution providing microcontroller unit (MCU), memory,
analog, and digital peripheral functions in a single chip. The CY8C36 family offers a modern method of signal acquisition, signal
processing, and control with high accuracy, high bandwidth, and high flexibility. Analog capability spans the range from thermocouples
(near DC voltages) to ultrasonic signals. The CY8C36 family can handle dozens of data acquisition channels and analog inputs on
every general-purpose input/output (GPIO) pin. The CY8C36 family is also a high-performance configurable digital system with some
part numbers including interfaces such as USB, multi-master inter-integrated circuit (I
2
C), and controller area network (CAN). In
addition to communication interfaces, the CY8C36 family has an easy to configure logic array, flexible routing to all I/O pins, and
current DAC a high-performance single cycle 8051 microprocessor core. You can easily create system-level designs using a rich
library of prebuilt components and boolean primitives using PSoC Creator™, a hierarchical schematic design entry tool. The CY8C36
family provides unparalleled opportunities for analog and digital bill of materials integration while easily accommodating last minute
design changes through simple firmware updates.
Features
Single cycle 8051 CPU core
DC to 67 MHz operation
Multiply and divide instructions
Flash program memory, up to 64 KB, 100,000 write cycles,
20 years retention, and multiple security features
512-byte flash cache
Up to 8-KB flash error correcting code (ECC) or configuration
storage
Up to 8 KB SRAM
Up to 2 KB electrically erasable programmable
read-only memory (EEPROM), 1 M cycles, and 20 years
retention
24-channel direct memory access (DMA) with multilayer
AHB
[1]
bus access
• Programmable chained descriptors and priorities
• High bandwidth 32-bit transfer support
Low voltage, ultra low-power
Wide operating voltage range: 0.5 V to 5.5 V
High efficiency boost regulator from 0.5-V input through
1.8-V to 5.0-V output
0.8 mA at 3 MHz, 1.2 mA at 6 MHz, 6.6 mA at 48 MHz
Low-power modes including:
• 1-µA sleep mode with real-time clock (RTC) and
low-voltage detect (LVD) interrupt
• 200-nA hibernate mode with RAM retention
Versatile I/O system
28 to 72 I/O (62 GPIOs, eight special input/outputs (SIO), two
USBIOs
[2]
Any GPIO to any digital or analog peripheral routability
LCD direct drive from any GPIO, up to 46 × 16 segments
[2]
CapSense
®
support from any GPIO
[3]
1.2-V to 5.5-V I/O interface voltages, up to four domains
Maskable, independent interrupt request (IRQ) on any pin or
port
Schmitt-trigger transistor-transistor logic (TTL) inputs
All GPIO configurable as open drain high/low,
pull-up/pull-down, High Z, or strong output
Configurable GPIO pin state at power-on reset (POR)
25 mA sink on SIO
Digital peripherals
20 to 24 programmable logic devices (PLD) based universal
digital blocks (UDB)
Full CAN 2.0b 16-receive (Rx), 8-transmit (Tx) buffers
[2]
Full-Speed (FS) USB 2.0 12 Mbps using internal oscillator
[2]
Up to four 16-bit configurable timer, counter, and PWM blocks
67-MHz, 24-bit fixed point digital filter block (DFB) to
implement finite impulse response (FIR) and infinite impulse
response (IIR) filters
Library of standard peripherals
• 8-, 16-, 24-, and 32-bit timers, counters, and PWMs
• Serial peripheral interface (SPI), universal asynchronous
transmitter receiver (UART), I
2
C
• Many others available in catalog
Library of advanced peripherals
• Cyclic redundancy check (CRC)
• Pseudo random sequence (PRS) generator
• Local interconnect network (LIN) bus 2.0
• Quadrature decoder
Analog peripherals (1.71 V V
DDA
5.5 V)
1.024 V ± 0.1% internal voltage reference across –40 °C to
+85 °C
Configurable delta-sigma ADC with 8- to12-bit resolution
• Programmable gain stage: ×0.25 to ×16
• 12-bit mode, 192-ksps, 66-dB signal to noise and distortion
ratio (SINAD), ±1-bit INL/DNL
Up to four 8-bit, 8-Msps IDACs or 1-Msps VDACs
Four comparators with 95-ns response time
Up to four uncommitted opamps with 25 mA drive capability
Up to four configurable multifunction analog blocks. Example
configurations are programmable gain amplifier (PGA),
transimpedance amplifier (TIA), mixer, and sample and hold
CapSense support
Programming, debug, and trace
JTAG (4-wire), serial wire debug (SWD) (2-wire), and single
wire viewer (SWV) interfaces
Eight address and one data breakpoint
4-KB instruction trace buffer
Bootloader programming supportable through I
2
C, SPI,
UART, USB, and other interfaces
Precision, programmable clocking
3- to 62-MHz internal oscillator over full temperature and
voltage range
4- to 25-MHz crystal oscillator for crystal PPM accuracy
Internal PLL clock generation up to 67 MHz
32.768 kHz watch crystal oscillator
Low-power internal oscillator at 1, 33, and 100 kHz
Temperature and packaging
–40 °C to +85 °C degrees industrial temperature
48-pin SSOP, 48-pin QFN, 68-pin QFN, and 100-pin TQFP
package options
Notes
1. AHB – AMBA (advanced microcontroller bus architecture) high-performance bus, an ARM data transfer bus
2. This feature on select devices only. See Ordering Information on page 116 for details.
3. GPIOs with opamp outputs are not recommended for use with CapSense.
