CJ1 Ordering Guide
B-118
Programmable Controller
CJ1
CPU Selection
J CPUs
CPU Model Description/Specifications
Part number
No. of I/O
points
Max. no. of modules,
Max. no. of expansions
(See Note 2.)
Program
capacity
Data memory capacity
(See Note 1.)
LD
instruction
processing
speed
Standards
2,560
40 modules, up to 3
expansion racks
120K steps 256K words
(DM: 32K words,
EM: 32K words x 7 banks)
0.02 µs UC, CE
CJ1H-CPU66H
40 modules, up to 3
expansion racks
60K steps 128K words
(DM: 32K words,
EM: 32K words x 3 banks)
CJ1H-CPU65H
1,280
40 modules, up to 3
expansion racks
60K steps 128K words
(DM: 32K words,
EM: 32K words x 3 banks)
0.04 µs
CJ1G-CPU45H
30 modules, up to 2
expansion racks
30K steps 64K words
(DM: 32K words,
EM: 32K words x 1 bank)
CJ1G-CPU44H
960
30 modules, up to 2
expansion racks
20K steps 64K words
(DM: 32K words,
EM: 32K words x 1 bank)
CJ1G-CPU43H
30 modules, up to 2
expansion racks
10K steps 64K words
(DM: 32K words,
EM: 32K words x 1 bank)
CJ1G-CPU42H
640 20 modules,
1 expansion rack
20K steps
32K words (DM only,
no EM)
.1 µs
CJ1M-CPU23
320
10 modules, no
i
k
10K steps
)
CJ1M-CPU22
160
,
expansion racks
5K steps CJ1M-CPU21
640 20 modules,
1 expansion rack
20K steps
32K words (DM only,
no EM)
.1 µs
CJ1M-CPU13
320
10 modules, no
i
k
10K steps
)
CJ1M-CPU12
160
,
expansion racks
5K Steps CJ1M-CPU11
Note: 1. The available data memory capacity is the sum of the Data Memory (DM) and the Extended Data Memory (EM). However,
thereisnoEMonCJ1MCPUs.
2. Three CJ1M CPUs (CJ1M-CPU21, CJ1M-CPU22 and CJ1M-CPU23) also incorporate built-in I/O. Refer to the CPU Overview
Section for more information.
J Memory Cards
Item Description/Specifications Standards Part number
Flash Memory Cards 15 MB L, CE HMC-EF172
y
30 MB
,
HMC-EF372
64 MB HMC-EF672
Memory Card Adapter Mounts a memory card to fit the PCMCIA card slot on a computer HMC-AP001
J Batteries
Item Description/Specifications Standards Part number
Battery Set Can also be used with CPM2A and CQM1H PLCs.
This battery cannot be used for CS1 Series PLCs.
L, CE CPM2A-BAT01
Can be used with CJ1M only.
This battery cannot be used for CJ1G/H, CPM2A, or CS1 Series
PLCs.
CJ1W-BAT01
