XILINX PROGRAMMER QUALIFICATION SPECIFICATION
XC17VXX, XC17SXXA Family
05/01 Rev. 3.0 1
Description
The XC17VXX(17V08 and 17V16 are described in another specification) and XC17SXXA Configuration
PROMs provide easy-to-use, cost-effective configuration memory for Xilinx Field Programmable Gate
Arrays.
These devices use a simple serial-access to configure one or more LCA devices. The user can select
the polarity of the reset function by programming a special bit. These devices are fully compatible and
can be cascaded with other members of the XC1700 family.
Pin Assignments:
Function (PD8/VO8) *(PC20/SO20) VQ44 PLCC44
Vpp 7 18 35 41
Vcc 8 20 38 44
Gnd 5 11 18 24
CLK 2 3 43 5
4 10 15 21
Reset/
3 8 13 19
6 13 21 27
D0 1 1 40 2
* Note: The pin definition of the PC20 package is different from the PC20 package for
the older PROM devices (eg. XC1701L-PC20)
Programming Overview
The XC17VXX and XC17SXX devices are one-time programmable (OTP) devices, organized as
follows:
XC17V04 XC17S200A
4,194,304 X 1 bit 1,679,360 X 1 bit
XC17V02 XC17S50A, XC17S100A, and XC17S150A
2,097,152 X 1 bit 1,048,576 X 1 bit
XC17V01 ** XC17S15A and XC17S30A
1,679,360 X 1 bit 524,288 X 1 bit
XC17S300A
2,097,152 X 1 bit
** Note: The density of the XC17V01 is different from the older devices in this density (i.e.
XC1701L)
