November 9, 1998 (Version 3.1) 7-3
7
Features
• Complete line of four related Field Programmable Gate
Array product families
- XC3000A, XC3000L, XC3100A, XC3100L
• Ideal for a wide range of custom VLSI design tasks
- Replaces TTL, MSI, and other PLD logic
- Integrates complete sub-systems into a single
package
- Avoids the NRE, time delay, and risk of conventional
masked gate arrays
• High-performance CMOS static memory technology
- Guaranteed toggle rates of 70 to 370 MHz, logic
delays from 7 to 1.5 ns
- System clock speeds over 85 MHz
- Low quiescent and active power consumption
• Flexible FPGA architecture
- Compatible arrays ranging from 1,000 to 7,500 gate
complexity
- Extensive register, combinatorial, and I/O
capabilities
- High fan-out signal distribution, low-skew clock nets
- Internal 3-state bus capabilities
- TTL or CMOS input thresholds
- On-chip crystal oscillator amplifier
• Unlimited reprogrammability
- Easy design iteration
- In-system logic changes
• Extensive packaging options
- Over 20 different packages
- Plastic and ceramic surface-mount and pin-grid-
array packages
- Thin and Very Thin Quad Flat Pack (TQFP and
VQFP) options
• Ready for volume production
- Standard, off-the-shelf product availability
- 100% factory pre-tested devices
- Excellent reliability record
• Complete Development System
- Schematic capture, automatic place and route
- Logic and timing simulation
- Interactive design editor for design optimization
- Timing calculator
- Interfaces to popular design environments like
Viewlogic, Cadence, Mentor Graphics, and others
Additional XC3100A Features
• Ultra-high-speed FPGA family with six members
- 50-85 MHz system clock rates
- 190 to 370 MHz guaranteed flip-flop toggle rates
- 1.55 to 4.1 ns logic delays
• High-end additional family member in the 22 X 22 CLB
array-size XC3195A device
• 8 mA output sink current and 8 mA source current
• Maximum power-down and quiescent current is 5 mA
• 100% architecture and pin-out compatible with other
XC3000 families
• Software and bitstream compatible with the XC3000,
XC3000A, and XC3000L families
XC3100A combines the features of the XC3000A and
XC3100 families:
• Additional interconnect resources for TBUFs and CE
inputs
• Error checking of the configuration bitstream
• Soft startup holds all outputs slew-rate limited during
initial power-up
• More advanced CMOS process
Low-Voltage Versions Available
• Low-voltage devices function at 3.0 - 3.6 V
• XC3000L - Low-voltage versions of XC3000A devices
• XC3100L - Low-voltage versions of XC3100A devices
0
XC3000 Series
Field Programmable Gate Arrays
(XC3000A/L, XC3100A/L)
November 9, 1998 (Version 3.1)
07*
Product Description
R
Device
Max Logic
Gates
Typical Gate
Range
CLBs Array
User I/Os
Max
Flip-Flops
Horizontal
Longlines
Configuration
Data Bits
XC3020A, 3020L, 3120A 1,500 1,000 - 1,500 64 8 x 8 64 256 16 14,779
XC3030A, 3030L, 3130A 2,000 1,500 - 2,000 100 10 x 10 80 360 20 22,176
XC3042A, 3042L, 3142A, 3142L 3,000 2,000 - 3,000 144 12 x 12 96 480 24 30,784
XC3064A, 3064L, 3164A 4,500 3,500 - 4,500 224 16 x 14 120 688 32 46,064
XC3090A, 3090L, 3190A, 3190L 6,000 5,000 - 6,000 320 16 x 20 144 928 40 64,160
XC3195A 7,500 6,500 - 7,500 484 22 x 22 176 1,320 44 94,984
Product Obsolete or Under Obsolescence
