ATWILC1000-MR1100A DATASHEET
IEEE 802.11 b/g/n Link Controller SoC
Datasheet
Description
The Atmel
®
ATWILC1000-MR1100A is a low-power consumption 802.11 b/g/n
IoT (Internet of Things) module which is specifically optimized for low power IoT
applications. The highly integrated module features small form factor (14.48 x
13.46 x 3.35mm) while fully integrating Power Amplifier, LNA, Switch, and Power
Management. With seamless roaming capabilities and advanced security, it
could be interoperable with various vendors’ 802.11b/g/n Access Points in
wireless LAN. The module provides SPI and SDIO to interface to host controller.
Features
IEEE
®
802.11 b/g/n 20MHz (1x1) solution
Single spatial stream in 2.4GHz ISM band
Integrated PA and T/R Switch
Superior Sensitivity and Range via advanced PHY signal processing
Advanced Equalization and Channel Estimation
Advanced Carrier and Timing Synchronization
Wi-Fi Direct
®
and Soft-AP support
Supports IEEE 802.11 WEP, WPA, WPA2 Security
Supports China WAPI security
Superior MAC throughput via hardware accelerated two-level A-MSDU/A-
MPDU frame aggregation and block acknowledgement
On-chip memory management engine to reduce host load
SPI, SDIO, UART, and I
2
C host interfaces
2-/3-wire Bluetooth
®
coexistence interface
Operating temperature range of -40 to +85°C
Power save modes:
– <1µA Deep Power Down mode typical @3.3V I/O
– 280µA Doze mode with chip settings preserved (used for beacon monitoring)
– On-chip low power sleep oscillator
– Fast host wake-up from Doze mode by a pin or host I/O transaction
Atmel-42432A-WILC1000-MR1100PA-SmartConnect-Datasheet_032015
