This hardware specification contains detailed information on power considerations, DC/AC
electrical characteristics, and AC timing specifications for the MPC860 family.
This hardware specification covers the following topics:
Topic Page
Section 1, “Overview” 2
Section 2, “Features” 2
Section 3, “Maximum Tolerated Ratings” 6
Section 4, “Thermal Characteristics” 7
Section 5, “Power Dissipation” 8
Section 6, “DC Characteristics” 8
Section 7, “Thermal Calculation and Measurement” 10
Section 8, “Layout Practices” 12
Section 9, “Bus Signal Timing” 12
Section 10, “IEEE 1149.1 Electrical Specifications” 40
Section 11, “CPM Electrical Characteristics” 42
Section 12, “UTOPIA AC Electrical Specifications” 65
Section 13, “FEC Electrical Characteristics” 67
Section 14, “Mechanical Data and Ordering Information” 71
Section 15, “Document Revision History” 76
Advance Information
MPC860EC
Rev. 6.3 9/2003
MPC860 Family
Hardware Specifications
