User's Guide
SNVA304A–April 2008–Revised May 2013
AN-1756 LM3481 Evaluation Board
1 Introduction
The LM3481 is a current mode, low side N channel FET controller. It can be utilized in numerous
configurations including a Boost, Flyback or SEPIC (Single Ended Primary Inductor Converter). This
evaluation board demonstrates the flexibility of the LM3481 in a boost topology. The operating conditions
for the evaluation board are listed below:
3V ≤ V
IN
≤ 11V
V
OUT
= 12V
0A ≤ I
OUT
≤ 1.5A
The circuit and bill of materials for this design are given below:
Figure 1. Circuit Diagram
All trademarks are the property of their respective owners.
1
SNVA304A–April 2008–Revised May 2013 AN-1756 LM3481 Evaluation Board
Submit Documentation Feedback
Copyright © 2008–2013, Texas Instruments Incorporated
