EVAL-ADM1062TQEBZ – EVAL-ADM1169LQEBZ User Guide
UG-063
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluating the ADM1062 to ADM1169 for Complex Sequencing
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. C | Page 1 of 20
FEATURES
Full-featured evaluation kits for ADM1062 to ADM1169
I²C interface supports all product-related software
10 adjustable voltages reference for input emulation
Switch-controlled, open-drain/push-pull digital inputs
Extra headers for easy probing
Includes point to point patch cables for easy wiring
Multiboard cascade support
EVALUATION KIT CONTENTS
EVAL-ADM1062CASZ to EVAL-ADM1169CASZ
evaluation board
samples of the relevant device are included
ADM1062 to ADM1169 device socket
8-way, 150 mm Micromatch ribbon cable
Patch cables
ADDITIONAL EQUIPMENT NEEDED
USB-to-I²C dongle USB-SDP-CABLEZ
9 V to 14.4 V power supply
RELATED DOCUMENTS
ADM1062 to ADM1169 data sheets
SOFTWARE NEEDED
ADM1062 to ADM1169 evaluation software
GENERAL DESCRIPTION
This user guide describes how to use the ADM1062 to
ADM1169 evaluation kits. The kits provide all of the support
circuitry required to operate the ADM1062/ADM1063/
ADM1064/ADM1065/ADM1066/ADM1067/ADM1068/
ADM1069/ADM1166/ADM1168/ADM1169 (hereafter referred
to as ADM1062 to ADM1169) in their various modes and
configurations, including multiple board setups. The ADM1062
to ADM1169 data sheets, available at www.analog.com, provide
additional information, and should be consulted when using the
evaluation board. All documents and software tools are
available at www.analog.com/power-management.
Note that USB-SDP-CABLEZ is not included in the evaluation
kit and should be ordered separately. Only one dongle is
required in multiboard cascade setup. One device socket is
included in each kit. Sockets for different device packages are
not included. Refer to the
Socket Selection Guide s
ection for
details regarding the corresponding socket types.
EVALUATION KIT SELECTION GUIDE
Table 1. Contents of Available Evaluation Kits
Evaluation Kit Model Contains Evaluation Board Contains IC Socket Corresponding Devices
EVAL-ADM1062TQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xTQZ ADM1062ASUZ
EVAL-ADM1063TQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xTQZ ADM1063ASUZ
EVAL-ADM1064TQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xTQZ ADM1064ASUZ
EVAL-ADM1065TQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xTQZ ADM1065ASUZ
EVAL-ADM1066TQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xTQZ ADM1066ASUZ
EVAL-ADM1067TQEBZ
EVAL-ADM1062-69CASZ
SOCKET-ADM106xTQZ
ADM1067ASUZ
EVAL-ADM1068LQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xLQZ ADM1068ASTZ
EVAL-ADM1069LQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xLQZ ADM1069ASTZ
EVAL-ADM1166TQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xTQZ ADM1166ASUZ
EVAL-ADM1168LQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xLQZ ADM1168ASTZ
EVAL-ADM1169LQEBZ EVAL-ADM1062-69CASZ SOCKET-ADM106xLQZ ADM1169ASTZ
