User's Guide
SLVUAC3A–October 2014–Revised July 2015
TPS82681xxEVM-589 Evaluation Module
The TPS82681xxEVM-589 facilitates the evaluation of the TPS8268xxx MicroSiP™ module family. There
are two EVMs in this family: TPS8268105EVM-589 (PWR589-001) and TPS8268180EVM-589 (PWR589-
002). PWR589-001 outputs a 1.05-V output voltage at up to 1.6 A of output current, while PWR589-002
outputs a 1.80-V output voltage at up to 1.6 A of output current. Both EVMs operate from input voltages
between 2.5 V and 5.5 V
Contents
1 Introduction ................................................................................................................... 1
2 Setup .......................................................................................................................... 2
3 TPS82681xxEVM-589 Test Results....................................................................................... 2
4 Board Layout ................................................................................................................. 3
5 Schematic and Bill of Materials ............................................................................................ 5
List of Figures
1 Top Assembly ................................................................................................................ 3
2 Top Silkscreen Layer........................................................................................................ 3
3 Top Copper Layer ........................................................................................................... 4
4 Bottom Copper Layer........................................................................................................ 4
5 TPS82681xxEVM-589 Schematic ......................................................................................... 5
List of Tables
1 Performance Specification Summary ..................................................................................... 1
2 TPS82681xxEVM-589 Bill of Materials ................................................................................... 5
1 Introduction
The TPS8268xxx are synchronous, step-down modules in a 2.3- x 2.9- x 1-mm package. All required
passives are included.
1.1 Performance Specification
Table 1 provides a summary of the TPS82681xxEVM-589 performance specifications.
Table 1. Performance Specification Summary
Specification Test Conditions Min Typ Max Unit
Input Voltage 2.5 3.6 5.5 V
Output Voltage Setpoint TPS8268105EVM-589 1.05 V
TPS8268180EVM-589 1.8
Output Current 0 1600 mA
MicroSiP is a trademark of Texas Instruments.
1
SLVUAC3A–October 2014–Revised July 2015 TPS82681xxEVM-589 Evaluation Module
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated
