Please find our works drawings for the parts supplied to Farnell. The parts are
modified motors from the base motors (i.e. reduced shaft ready for use with the
Gearheads or back shaft reduced ready for the encoder)
I have enclosed the Maxon base part number and the catalogue PDF that gives the
electrical specifications
121391 MOTOR, 26MMDIA, 12VDC, 11W – Farnell Order Code 176-1305.
Maxon base part no 110937
121394 MOTOR, 26MMDIA, 24VDC, 11W – Farnell Order Code 176-1306.
Maxon base part no 110940
243066 MOTOR, 32MMDIA, 12VDC, 15W, THRO S – Farnell Order Code1761307
Maxon base part no 236653
240987 MOTOR, 32MMDIA, 24VDC, 15W, THRO S – Farnell Order Code1761308
Maxon base part no 236655
137576 MOTOR, 36MMDIA, 24VDC, 70W – Farnell Order Code 1761309
Maxon base no 118798
Maxon motor UK Ltd
Maxon House, Hogwood Lane, Finchampstead, Berkshire, RG40 4QW
Tel: +44 (0) 118 9733337 Fax: +44 (0) 118 9737472
