VN
VP
HV TX
LVRX
1 Channel
of TX810
TX810
www.ti.com
SLLS996A –SEPTEMBER 2009–REVISED APRIL 2010
8-Channel, Programmable T/R Switch for Ultrasound
Check for Samples: TX810
1
FEATURES
DESCRIPTION
2
• Compact T/R Switch for Ultrasound
The TX810 provides an integrated solution for a wide
range of ultrasound applications. It is an 8 channel,
• Flexible Programmability
current programmable, transmit/receive switch in a
– 8 Bias Current Settings
small 6mm × 6mm package.
– 8 Power/Performance Combinations
The internal diodes limit the output voltage when high
– Easy Power-Up/Down control
voltage transmitter signals are applied to the input.
• Fast Wake Up Time
While the insertion loss of TX810 is minimized during
receive mode.
• Dual Supply Operation
• Optimized Insertion Loss
Unlike conventional T/R switches, the TX810 contains
a 3-bit interface used to program bias current from
7mA to 0mA for different performance and power
APPLICATIONS
requirements. When the TX810 bias current is set as
• Medical Ultrasound
0mA (i.e., high-impedance mode), the device is
• Industrial Ultrasound
configured as power-down mode. In the
high-impedance mode, TX810 does not add
additional load to high-voltage transmitters. In
addition, the device can wake up from power-down
mode in less than 1µs. With these advanced
programmability features, significant power saving
can be achieved in systems.
Figure 1. Block Diagram of TX810
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2PowerPAD is a trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Copyright © 2009–2010, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
